NGC 6960 - Veil Nebula
Zoom
Go To
NGC 6960 - Veil Nebula
Edmonton, Alberta
2015-Jul-01
Ha,SII 6x600s OIII 4x600s, total 2hr 40min
SGP, MaximDL, CPS
NP101is, STF-8300M, A80Mf, LSX2, EQ8
The Veil Nebula is a supernova remmnant found in the constellation Cygnus.
The bright star in the foreground is not part of the nebula, but it makes for a striking image

This is my first tri-color narrowband image. The image is made up of 10 minute sub-frames taken with Ha, OIII and SII filters. The resulting images were mapped to red, blue and green respectively. The unprocessed image is pretty low quality and took a fair bit of clean up just to get it to this point.

Longer sub-frame exposure times would have probably helped. Subsequent testing on other targets showed that the sub-frames exposures should to be 20 minutes or more for a good sample of the narrowband wavelengths.

It also didn't help that the image was taken from the city under a full moon. Although the narrowband filters help, they can only do so much. However, this image does demonstrate that the techinque works and it looks like fairly good detail can be obtained with a few tweaks and a little less moonlight.

NGC 6960 - Veil Nebula Images
NGC6960 - The Veil Nebula. Imaged on an NP101is refractor with a 60Da DSLR camera
NP101is, 60Da
NGC6960 - The Veil Nebula. Narrowband image from an NP101is refractor with an STF-8300M CCD camera.
NP101is, Ha-OIII-SI
